​Parallel Battery Cable

Two batteries in parallel are only as good as the cable that joins them. Short, heavy and equal, so the bank behaves like one battery.
View as

Parallel Battery Cable

RG-Logo-Icon

Overview

Parallel Battery Cable Overview

About Parallel Battery Cable

Two batteries in parallel are only as good as the cable that joins them.

Link two batteries with cable that is too thin, or with links of different lengths, and they stop being one bank. The battery closer to the load does more of the work, discharges deeper, ages faster, and after a season the two are no longer matched. The bank behaves like the weaker of the two rather than the sum.

Parallel cable helps by being short, heavy and equal. Short so the resistance between the batteries is close to nothing. Heavy so the current between them moves with as little voltage drop and heating as the size allows. Equal so neither battery sees a longer path than the other. Cable alone does not balance a bank: how the batteries are arranged and where the load and charge connect matter as much, and the battery maker's paralleling instructions govern both.

The kits here are cut to length and lugged for that job, in positive and negative pairs. Size them to the current the bank will actually carry and the length of the link, not to the batteries' amp hour rating, and check the terminal fit and the protection the bank needs. The bare heavy cable sits alongside, by the half metre, for banks that need a different length or a third battery.

A link rated below the bank's peak draw is the weakest point in the whole system, and it is the one that heats up first when the inverter starts.

FAQs

Parallel Battery Cable FAQs

How do I wire two 12V batteries in parallel using battery cables?

Parallel wiring involves connecting the positive terminal of the first battery to the positive terminal of the second, and doing the same for the negative terminals. This configuration keeps the system voltage at 12 volts while doubling your total storage capacity in amp hours.

Using batteries of the same age, brand, and chemistry is a smart move to prevent the newer battery from discharging into the older one. Thicker cabling is preferred for these links to handle the increased current flow that a larger bank produces. This setup is a practical way to extend your off grid stay without changing your 12V appliances.

Explore our AGM Deep Cycle Batteries to find matching units, or see our Battery Cable for heavy gauge wiring options.

Do parallel battery cables need to be the exact same length?

Yes, the cables linking your batteries must be the exact same length and gauge. Because electrical resistance increases with cable length, even a small difference can cause the batteries to charge and discharge at different rates.

If one path is shorter, the battery connected to it will work harder and fail sooner than the others in the bank. Keeping your links identical helps balance the load across every cell, which preserves the service life of your entire power system. This simple step is a vital part of building a professional and balanced 12V setup.

Browse our Battery Cable to find the right gauge for your parallel links.

How do I connect a load to batteries wired in parallel?

You should connect your main positive lead to the first battery in the bank and your main negative lead to the last battery. This diagonal connection method forces the current to travel through every battery in the parallel group equally.

Connecting both leads to a single battery in the bank often leads to that specific battery doing most of the work while the others sit idle. A balanced draw helps maintain battery health and capacity, especially when you are running high load appliances. This approach allows your entire bank to act as one single, powerful unit.

Check out our Battery Monitors & Shunts to track this balance, or see our 12V Pure Sinewave Inverters for high draw connections.
